Market leaders

Expanded Metal Roll

Rolls of expanded metal are traditionally used in the blacksmith’s shop. They are practical to dose the material requirements according to the progress of each project.

Quote

Roll size

from cal. 26 to cal. 9

Thickness

BENEFITS

DIVERSIDAD DE MODELOS
Ancho de Rollo
Líderes

Capacidad para crear un amplio rango de rollos

LADESA cuenta con la mayor gama del mercado en dimensiones de rombo, espesor, y medidas disponibles para un sinfín de aplicaciones en herrería, construcción y soluciones industriales.

3 y 4 pies para infinidad de usos.

Estas opciones ayudan en la
optimización cuando se utiliza este producto en diversos tipos de estructuras e instalaciones.

Ayudamos a optimizar tu productividad y alcanzar tus objetivos comerciales.

Contamos con la infraestructura para proveer las necesidades más especificas, gracias a nuestra calidad y certificaciones.

DIVERSIDAD DE MODELOS
Ancho de Rollo
Líderes

Capacidad para crear un amplio rango de rollos

LADESA cuenta con la mayor gama del mercado en dimensiones de rombo, espesor, y medidas disponibles para un sinfín de aplicaciones en herrería, construcción y soluciones industriales.

3 y 4 pies para infinidad de usos.

Estas opciones ayudan en la
optimización cuando se utiliza este producto en diversos tipos de estructuras e instalaciones.

Ayudamos a optimizar tu productividad y alcanzar tus objetivos comerciales.

Contamos con la infraestructura para proveer las necesidades más especificas, gracias a nuestra calidad y certificaciones.

Benefits

METAL-RED (MR) PATTERNS

Patterns

Natural expanded metal without additional finishing. It consists of diamonds that are oriented at an angle to the original plane of the solid sheet.

A4-26 MR

B8-26 MR

H39-14 MR

J48-10 MR

See all our models in the specifications table. Go to specifications table for METAL-RED.

PLANO-RED (PR) PATTERNS

Patterns

Expanded metal subjected to a cold rolling process, which allows it to have a completely smooth surface. The product is made up of diamonds in a horizontal position with respect to the original plane of the solid sheet.

C13-26 PR
D19-20 PR
E23-22 PR
G32-20 PR

See all our models in the specifications table. Go to specifications table for PLANO-RED.

Applications

Applications

The applications of Expanded Metal are many and varied, these are just to mention a few.

  • Area dividers
  • Racks and shelves
  • Stairs
  • Conveyor baskets
  • Protectors
  • Railings
  • Containers

Roll size

from cal. 26 to cal. 9

Thickness

Categories

Materials

Steel

Galvanized Sheet

Aluminum

Copper

Certifications

Do you have any questions or require specifications for a product?

Do not hesitate to contact us, enter your information and we will contact you.

Technical Specifications

Tech Specs

UNFOLDED METAL IN COILS WITHOUT IRONING CARBON STEEL

See our measurements for METAL-RED™ in carbon-ironed steel.

Catálogo Abertura de la Malla LCR Pulg. Abertura de la Malla LCR mm. Abertura de la Malla LLR Pulg. Abertura de la Malla LLR mm. Espesor Pulg. Espesor mm. Sección Pulg. Sección mm. Peso Lbs / pie2 Peso Kgs / mts.2 Dimensión del Rollo LLR Ancho mts. Dimensión del Rollo LLR Largo mts.
AA-26 MR 0.12 3.1 0.25 6.3 0.017 0.45 0.039 1.0 0.50 2.44 0.91 & 1.22 11
B8-26 MR 0.19 4.7 0.39 9.9 0.017 0.45 0.039 1.0 0.30 1.45 0.91 & 1.22 11
B9-24 MR 0.19 4.7 0.39 9.9 0.024 0.61 0.039 1.0 0.40 1.95 0.91 & 1.22 11
B10-22 MR 0.19 4.7 0.39 9.9 0.030 0.76 0.039 1.0 0.50 2.44 0.91 & 1.22 11
B11-20 MR 0.19 4.7 0.39 9.9 0.035 0.91 0.039 1.0 0.60 2.93 0.91 & 1.22 11
C13-26 MR 0.31 7.9 0.62 15.8 0.017 0.45 0.039 1.0 0.18 0.90 0.91 & 1.22 11
C14-24 MR 0.31 7.9 0.62 15.8 0.024 0.61 0.039 1.0 0.25 1.20 0.91 & 1.22 11
C15-22 MR 0.31 7.9 0.62 15.8 0.030 0.76 0.059 1.5 0.47 2.30 0.91 & 1.22 11
C16-20 MR 0.31 7.9 0.62 15.8 0.035 0.91 0.059 1.5 0.57 2.77 0.91 & 1.22 11
D17-24 MR 0.44 11.1 0.87 22.2 0.024 0.61 0.059 1.5 0.28 1.35 0.91 & 1.22 11
D18-22 MR 0.44 11.1 0.87 22.2 0.030 0.76 0.059 1.5 0.35 1.70 0.91 & 1.22 11
D19-20 MR 0.44 11.1 0.87 22.2 0.035 0.91 0.059 1.5 0.41 2.00 0.91 & 1.22 11
D20-18 MR 0.44 11.1 0.87 22.2 0.047 1.21 0.059 1.5 0.55 2.70 0.91 & 1.22 11
D21-16 MR 0.44 11.1 0.87 22.2 0.060 1.52 0.059 1.5 0.69 3.35 0.91 & 1.22 11
E23-22 MR 0.50 12.7 1.23 31.2 0.030 0.76 0.078 2.0 0.41 2.00 0.91 & 1.22 11
E24-20 MR 0.50 12.7 1.23 31.2 0.035 0.91 0.078 2.0 0.49 2.40 0.91 & 1.22 11
E25-18 MR 0.50 12.7 1.23 31.2 0.047 1.21 0.078 2.0 0.67 3.25 0.91 & 1.22 11
E26-16 MR 0.50 12.7 1.23 31.2 0.060 1.52 0.078 2.0 0.84 4.10 0.91 & 1.22 11
E27-14 MR 0.50 12.7 1.23 31.2 0.075 1.90 0.078 2.0 1.04 5.10 0.91 & 1.22 11
G32-20 MR 0.75 19.0 1.62 41.2 0.035 0.91 0.098 2.5 0.37 1.80 0.91 & 1.22 11
G33-18 MR 0.75 19.0 1.62 41.2 0.047 1.21 0.098 2.5 0.49 2.40 0.91 & 1.22 11
G34-16 MR 0.75 19.0 1.62 41.2 0.060 1.52 0.098 2.5 0.61 3.00 0.91 & 1.22 11
G35-14 MR 0.75 19.0 1.62 41.2 0.075 1.90 0.098 2.5 0.78 3.80 0.91 & 1.22 11
H36-20 MR 0.98 25.0 2.00 50.8 0.035 0.91 0.118 3.0 0.36 1.75 0.91 & 1.22 11
H37-18 MR 0.98 25.0 2.00 50.8 0.047 1.21 0.118 3.0 0.47 2.30 0.91 & 1.22 11
H38-16 MR 0.98 25.0 2.00 50.8 0.060 1.52 0.118 3.0 0.59 2.90 0.91 & 1.22 11
H39-14 MR 0.98 25.0 2.00 50.8 0.075 1.90 0.118 3.0 0.74 3.60 0.91 & 1.22 11
H40-12 MR 0.98 25.0 2.00 50.8 0.104 2.66 0.118 3.0 1.05 5.15 0.91 & 1.22 11
H40-12L MR 0.98 25.0 2.00 50.8 0.090 2.28 0.107 2.7 0.80 3.91 0.91 & 1.22 11
J45-16 MR 1.33 33.8 3.00 76.2 0.060 1.52 0.157 4.0 0.57 2.80 0.91 & 1.22 11
J46-14 MR 1.33 33.8 3.00 76.2 0.075 1.90 0.157 4.0 0.72 3.50 0.91 & 1.22 11
J47-12 MR 1.33 33.8 3.00 76.2 0.104 2.66 0.157 4.0 1.00 4.90 0.91 & 1.22 11
J47-12L MR 1.33 33.8 3.00 76.2 0.090 2.28 0.124 3.2 0.68 3.34 0.91 & 1.22 11
J48-10 MR 1.33 33.8 3.00 76.2 0.134 3.42 0.157 4.0 1.28 6.25 0.91 & 1.22 11
J48-10L MR 1.33 33.8 3.00 76.2 0.120 3.04 0.147 3.7 1.08 5.27 0.91 & 1.22 11

METAL ROLLED FLAT ROLLED CARBON STEEL

See our sizes for PLANO-RED™ in carbon steel.

Catálogo Abertura de la Malla LCR Pulg. Abertura de la Malla LCR mm. Abertura de la Malla LLR Pulg. Abertura de la Malla LLR mm. Espesor Pulg. Espesor mm. Sección Pulg. Sección mm. Peso Lbs / pie2 Peso Kgs / mts.2 Dimensión del Rollo LLR Ancho mts. Dimensión del Rollo LCR Largo mts.
AA-26 PR 0.13 3.4 0.25 6.3 0.017 0.45 0.039 1.0 0.45 2.20 0.91 & 1.22 11
B8-26 PR 0.20 5.2 0.39 9.9 0.017 0.45 0.039 1.0 0.27 1.31 0.91 & 1.22 11
B9-24 PR 0.20 5.2 0.39 9.9 0.024 0.61 0.039 1.0 0.36 1.76 0.91 & 1.22 11
B10-22 PR 0.20 5.2 0.39 9.9 0.030 0.76 0.039 1.0 0.45 2.20 0.91 & 1.22 11
B11-20 PR 0.20 5.2 0.39 9.9 0.035 0.91 0.039 1.0 0.54 2.64 0.91 & 1.22 11
C13-26 PR 0.34 8.7 0.62 15.8 0.017 0.45 0.039 1.0 0.18 0.81 0.91 & 1.22 11
C14-24 PR 0.34 8.7 0.62 15.8 0.024 0.61 0.039 1.0 0.25 1.20 0.91 & 1.22 11
C15-22 PR 0.34 8.7 0.62 15.8 0.030 0.76 0.059 1.5 0.47 2.30 0.91 & 1.22 11
C16-20 PR 0.34 8.7 0.62 15.8 0.035 0.91 0.059 1.5 0.57 2.77 0.91 & 1.22 11
D17-24 PR 0.48 12.1 0.87 22.2 0.024 0.61 0.059 1.5 0.25 1.22 0.91 & 1.22 11
D18-22 PR 0.48 12.1 0.87 22.2 0.030 0.76 0.059 1.5 0.31 1.53 0.91 & 1.22 11
D19-20 PR 0.48 12.1 0.87 22.2 0.035 0.91 0.059 1.5 0.37 1.80 0.91 & 1.22 11
D20-18 PR 0.48 12.1 0.87 22.2 0.047 1.21 0.059 1.5 0.50 2.43 0.91 & 1.22 11
D21-16 PR 0.48 12.1 0.87 22.2 0.060 1.52 0.059 1.5 0.62 3.02 0.91 & 1.22 11
E23-22 PR 0.57 14.5 1.23 31.2 0.030 0.76 0.078 2.0 0.37 1.80 0.91 & 1.22 11
E24-20 PR 0.57 14.5 1.23 31.2 0.035 0.91 0.078 2.0 0.44 2.16 0.91 & 1.22 11
E25-18 PR 0.57 14.5 1.23 31.2 0.047 1.21 0.078 2.0 0.60 2.93 0.91 & 1.22 11
E26-16 PR 0.57 14.5 1.23 31.2 0.060 1.52 0.078 2.0 0.76 3.69 0.91 & 1.22 11
E27-14 PR 0.57 14.5 1.23 31.2 0.075 1.90 0.078 2.0 0.94 4.59 0.91 & 1.22 11
G32-20 PR 0.87 22.2 1.62 41.2 0.035 0.91 0.098 2.5 0.33 1.62 0.91 & 1.22 11
G33-18 PR 0.87 22.2 1.62 41.2 0.047 1.21 0.098 2.5 0.44 2.16 0.91 & 1.22 11
G34-16 PR 0.87 22.2 1.62 41.2 0.060 1.52 0.098 2.5 0.55 2.70 0.91 & 1.22 11
G35-14 PR 0.87 22.2 1.62 41.2 0.075 1.90 0.098 2.5 0.70 3.42 0.91 & 1.22 11
H36-20 PR 1.06 26.9 2.00 50.8 0.035 0.91 0.118 3.0 0.32 1.58 0.91 & 1.22 11
H37-18 PR 1.06 26.9 2.00 50.8 0.047 1.21 0.118 3.0 0.42 2.07 0.91 & 1.22 11
H38-16 PR 1.06 26.9 2.00 50.8 0.060 1.52 0.118 3.0 0.53 2.61 0.91 & 1.22 11
H39-14 PR 1.06 26.9 2.00 50.8 0.075 1.90 0.118 3.0 0.66 3.24 0.91 & 1.22 11
H40-12 PR 1.06 26.9 2.00 50.8 0.104 2.66 0.118 3.0 0.95 4.64 0.91 & 1.22 11
H40-12L PR 1.062 26.97 2.00 50.8 0.090 2.28 0.111 2.8 0.77 3.74 0.91 & 1.22 11
J45-16 PR 1.50 38.1 3.00 76.2 0.060 1.52 0.157 4.0 0.52 2.52 0.91 & 1.22 11
J46-14 PR 1.50 38.1 3.00 76.2 0.075 1.90 0.157 4.0 0.64 3.15 0.91 & 1.22 11
J47-12 PR 1.50 38.1 3.00 76.2 0.104 2.66 0.157 4.0 0.89 4.35 0.91 & 1.22 11
J47-12L PR 1.50 38.1 3.00 76.2 0.090 2.28 0.124 3.2 0.62 3.01 0.91 & 1.22 11
J48-10 PR 1.50 38.1 3.00 76.2 0.134 3.42 0.157 4.0 1.13 5.54 0.91 & 1.22 11
J48-10L PR 1.50 38.1 3.00 76.2 0.120 3.04 0.150 3.8 0.97 4.74 0.91 & 1.22 11
